Power adapter, especially switching power adapter, is a relatively new and rapidly developing engineering discipline. Therefore, the terminology used by power adapter companies to describe them is still developing, and there is no general consensus and complete definition yet.



Although the list below is not comprehensive enough, it also gives a more general understanding of some terminology and adds the author's definition to the commonly accepted usage in the industry at the time of publication of the book. In some cases, the general meaning of a term may differ from the special meaning in the application of power adapters. In this case, we first give the "general meaning" and then give the special meaning of the power adapter application, abbreviated as "special meaning".



Since the international standards and definitions for the power adapters of air purifiers have not yet been established, the definitions here need to be updated in time.









Ambient Temperature



General Meaning: Environmental Temperature



Special meaning: For convection cooling power adapter, it refers to the air temperature directly below the power adapter in the free air flow position. The power adapter for fan cooling refers to the air temperature at the fan inlet and the surface temperature of the heat exchanger for conductive cooling components.



Amplifier (Differential). An amplifier with two signal terminals whose output voltage amplitude and polarity are proportional to the voltage difference and polarity added to the inverted and the same input terminals.



Amplifier (Transconductance), an amplifier with two signal terminals, whose output current is proportional to the voltage difference between the input terminals.



Ancillary Function refers to all functions provided by the power adapter that are not directly related to the generation of stable output. When accessory functions are not considered to be major failures, they are sometimes overlooked in MTBF calculations.



Automatic Crossover.



Special meaning: This term is commonly used in laboratory-type variable power adapters with stable voltage and current characteristics. These power adapters can automatically switch between two operating states to respond to load changes or control adjustments of Korean certified power adapters. The running status is usually displayed by the indicator light of the front panel.



Auxiliary Output. Refers to a power adapter with multiple outputs. All outputs except the main output usually have a lower rated power and limited performance.
