360W open frame type medical power adaptor, ITE, CLASS B, LPS
P/N: KRE-OPS360W
Model: KRE-2401500D




Input: 115~230V 50/60Hz 4.5AMax
Output: 24V=15A

2 years warranty
10 years of industry experience
3 to 360 watts for your customized requirment

Two year warranty
Average working no trouble ＞50,000 hours
Product Electric Parameters




Input voltage
AC90V---264V
Input frequency
50-60Hz
Input surge
20A/120VAC
40A/230VAC




Output voltage can be adjusted
±10%
Start-up time
Leq 1S(input230V,Io=100%)
keep time
More than or equal to 20mS (input230V,Io=100%)
Voltage regulation
(Full load) leq 0.5%

built-in EMI filter
100% load test
Full range of input voltage
output voltage accurate and stable
Output over-voltage, over-current and short-circuit protection
Output low ripple and noise




According with GB4943, UL60950-1,EN60950-1 standards.
E M C standards
According with GB9254, EN55022 class A EN61347-2-13:2008 standards




Input---output
1500VAC/1min
Input---ground
1500VAC/1min
Input---ground
500VAC/1min




working temperature
- 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost)
Storage temperature
- 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost)
height above sea level:
Leq 2000M
cooling method:
Natural cooling air convection




Overload protection
105% - 150% rated power, automatic recovery
Over-voltage protection
105% - 150% of the rated voltage
