30VAC 1.2A AC/AC desktop type linear power supply, 30VAC 1.2A Linear adapter, Class IV, GEMS,SAA,EMC,ROHS, Universal input, customized design. Category number: KRE-LPD08 Model number: KRE-1802002LD
Input: 100-240VAC 50~60HZ
Output: 18VAC 2.0A
Power: 36W
Model Number: KRE-XXXYYYZLD "XXX"=050-300, The output voltage is DC5.0-30.0V, "YYY"=020-300， The output current is 0.20-3.0A, "Z" representing the input plug, 0-European plug, 1-British plug, 2-the Australian plug, 3-USA plug, 4- Japan plug, 5-China plug, 6-Korea plug. "L"=Linear power supply "D"= desktop type linear power supply
Low-temperature High-efficiency High-reliability Light and convenient plug in
Customized designs are accepted Design time: 2 days (maximum) Rated input voltage and frequency: 100V AC 60Hz (Japan), 120V AC 50/60Hz (North America), 220V AC 50Hz (China, Korea), 230 to 240V AC 50/60Hz (Europe, Russia), 240V AC 50/60Hz (Australia, New Zealand), 127 or 220V AC (Brazil) No load input power (240V AC): non-CEC Input plug: EU/VDC (EU), the US (North America), PSE (Japan), SAA (Aust, NZ), BS (UK, HK), Brazil, South Africa, CCC (China), EK (Korea) and more
DC output voltage: from 3 to 24V AC optional DC output current: 30 to 3,000mA (maximum) Output voltage precision: 5% Ripple and noise: 100mV Regulation: ±1% line, ±5% load DC output cord dimensions: 2.1 x 5.5 x 12mm, normal Wire length: 1.5 meters
CCTVs, securities, antennas, fans, radios, videos, toys, aquariums, desk lamps, LED lamps and more
Leakage current: 0.25mA maximum at 264V AC Burn-in: 100% full load, 40°C, 4 hours (minimum) MTBF: meets MIL-HDBK-217F over 60K hours, full load, 25°C
Short-circuit Thermal cut-off capability
EN61558-2-6 EN60950:2009; EN60065 PSE IEC60950, EN60065 AS/NZS 60950:2000, AS/NZS60065 CE (low-voltage Directive) UL1310, GB4943-2001
FCC parts 15 class B EN55022 class B AS/NZS3548, AS/NZS4251.1 class B EN55024/A1:2001 IEC61000-4-2; -3;-4;-5;-6; -11 GB9254-1998/GB17625.1-2003 CISPR22 class B CNS13438 class B
Very low-ripple and noise, very good regulation, low-disturbance noise but more heavy, bigger size, than switching power supply
Individual white box PE bag EI57 or EI66 type Carton size: 430 x 280 x 250mm 20 pieces per carton Gross weight: 18kg (maximum)
